Reliability, Serviceability and Comfort in a Durable Package. The CS-683E Soil Compactor has been designed to offer enhanced production capabilities, simplified service and exceptional operator comfort. Engine: Cat 3056E Turbocharged Diesel Engine delivers 129 kW (173 hp) and is built for performance and reliability without sacrificing fuel economy. Dual Propel Pumps: The exclusive dual pump propel system provides a separate balanced hydraulic flow to both the rear drive axle and the front drum drive motor. This system enables the operator to achieve superior gradeability and maintain machine control while compacting on a grade. Dual pumps also minimize drum and wheel spin-out in loose underfoot conditions. Vibratory System: Pod-style weight housings ensure peak vibratory performance and minimal service. Pods are replaceable and feature bearing lubrication change intervals of 3 years/3000 hours.

Dimensions
A. Overall Length	19.7 ft in	6000 mm
B. Overall Width	7 ft in	2133.6 mm
C. Height to Top of Cab	9.9 ft in	3020 mm
D. Wheelbase	9.5 ft in	2900 mm
E. Ground Clearance	20.7 in	525 mm
