Engineered to excel on the most demanding work sites. Combining power, rugged components and superior balance, the versatile D7G is designed for tough working conditions. It keeps material moving with the reliability and durability you expect from Caterpillar® machines. With a powertrain that is designed and built by Caterpillar, the D7G ensures compatibility, maximum performance and reliability. Comes with Work Tools and Ground Engaging Tools to provide the flexibility to match the machine to the job and maximizing performance.

Dimensions
A. LENGTH W/ BLADE	17.3 ft in	5280 mm
B. WIDTH OVER TRACKS	8.6 ft in	2620 mm
C. HEIGHT TO TOP OF CAB	10.7 ft in	3250 mm
D. LENGTH OF TRACK ON GROUND	8.9 ft in	2700 mm
E. GROUND CLEARANCE	1.1 ft in	347 mm
F. LENGTH W/O BLADE	13.7 ft in	4190 mm
Undercarriage
G. TRACK GAUGE	6.5 ft in	1980 mm
H. STANDARD SHOE SIZE	20 in	508 mm

Dimensions
A. Length w/ Blade	18.2 ft in	5559 mm
B. Width Over Tracks	ft in	mm
C. Height to Top of Cab	10.9 ft in	3336 mm
D. Length of Track on Ground	9.5 ft in	2896 mm
E. Ground Clearance	1.3 ft in	403.5 mm
F. Length w/o Blade	15.2 ft in	4619 mm
Undercarriage
G. Track Gauge	6.5 ft in	1981 mm
H. Standard Shoe Size	20.1 in	510 mm

The Cat D8 dozer has a long history of outstanding versatility, productivity and resale value. Because this bulldozer excels across a wide range of tasks, customers choose the D8 for everything from dozing, ripping, scraper work and land clearing to finish grading. And with features designed for even greater comfort, productivity and fuel efficiency, today’s D8 does even more to help you meet your business objectives.

Dimensions
A. LENGTH W/ BLADE	20.6 ft in	6265 mm
B. WIDTH OVER TRACKS	8.7 ft in	2642 mm
C. HEIGHT TO TOP OF CAB	11.3 ft in	3430 mm
D. LENGTH OF TRACK ON GROUND	10.5 ft in	3200 mm
E. GROUND CLEARANCE	1.7 ft in	528 mm
F. LENGTH W/O BLADE	16.3 ft in	4954 mm
Undercarriage
G. TRACK GAUGE	6.8 ft in	2083 mm
H. STANDARD SHOE SIZE	22 in	560 mm

D6H is designed for aggressive impact applications, yet has the necessary wear material for long life in abrasive conditions. D6H is designed to be disassembled for bushing turn service to maximize wear life. It can be resealed in applications that are limited by track seal life. For extreme applications, D6H can be configured with outrigger chains creating a tri-track or quad-track configuration. Blades, rippers and other implements are the tools that actually contact the material a dozer is working. They can be customized to a specific application and readily changed to meet varying job needs as the machine moves from site to site.

Dimensions
A. LENGTH W/ BLADE	17 ft in	5176 mm
B. WIDTH OVER TRACKS	10.3 ft in	3140.0000 mm
C. HEIGHT TO TOP OF CAB	10.3 ft in	3138 mm
D. LENGTH OF TRACK ON GROUND	10.7 ft in	3265 mm
E. GROUND CLEARANCE	1.3 ft in	382 mm
F. LENGTH W/O BLADE	14.7 ft in	4485 mm
Undercarriage
G. TRACK GAUGE	7.3 ft in	2225 mm
H. STANDARD SHOE SIZE	36 in	915 mm
